Designed a practical and simple control application on PC, you can download (SNP) files for radio design and simulation software. If you need to obtain S12 and S22, you need to manually replace the transceiver port wiring.
The TX/RX can measure the complete S11 and S21 parameters. The 50K-300MHz frequency range of the si5351 direct output provides 70dB dynamic, The extended 300M-900MHz band provides 60dB of dynamics, and the 900M-1.5GHz band is 40dB of dynamicsMULTIPLE FUNCTIONS: The default firmware main function is used for antenna performance measurement and lots of measurement types. ABS material case can protect the nanovna from damage during transportation and is dust-proofWIDE FREQUENCY RANGE: The improved frequency algorithm can use the odd harmonic extension of si5351 to support the measurement frequency up to 1.5GHz. Added SD card port, can save the measurement data or screenshots at any time.
UPGRADED NANOVNA-H: NanoVNA-H with extra 9 SMA calibrations and connectors, you will get SMA simple calibration kit OPEN x2, SHORT x2, LOAD x2, SMA female to female connector x2, SMA male to male connector x1.
